Trailer Light Power Module – TEKONSHA 119193
The Tekonsha Modulite product line has power modules designed to virtually eliminates additional electrical draw on the vehicle’s tail light circuits. They help to ensures maximum trailer light brightness for your trailer tail lights. It powers the trailer’s stop, turn, tail and running lights without overloading your vehicle electrical systems.
Attributes
- Compatibility: 2 Wire And 3 Wire System
- Bulb Type: Incandescent/ LED Bulbs
- Turn/Stop Light Ampere Rating (A): 4.2 Amp
- Tail Light Ampere Rating (A): 16 Amp
Features & Benefits
- Unit Is Rated For Up To 4.2 Ampere For Turns Or Stops Circuits And 16 Ampere For The Taillight Circuit
- Universal ModuLite Designed To Be Used On Most Vehicles Plus The Hard To Wire Vehicles
- Draws Power Directly From The Vehicle Battery And Uses Less Than 5mA Of The Vehicle Circuit For Sensing To Turn The Trailer Functions On And Off
- Will Work With Either LED And Incandescent Bulbs
- Has Integrated Re-Settable Short Circuit And Overload Protection, To Safeguard Itself And The Tow Vehicle From Shorts And Installation Wiring Mishaps
- Designed Not To Send Feedback Thru The Vehicle Circuits
- Trailer Brakes Will Override The Hazard Lamps When The Brake Is Activated
- Advanced Circuitry Works In All Standard Applications As Well As Vehicles With ST And STT Pulse Width Modulation Systems
- Interprets Or Decodes Multiplex Signal Inputs
- Limited 1 Year Warranty
