Trailer Tongue Jack; Square Topwind Jack – BULLDOG CANADA 190704
Bulldog’s 8,000 Pounds support capacity square jack serves the agricultural, industrial, construction, horse/livestock trailer, and utility/cargo trailer markets. We have packed “Big Jack Power” into this compact design. The compact design of these jacks makes them ideal for tight-fitting applications where 3 Inch and 4 Inch square tube jacks are too big. This is a perfect transition from Bulldog’s round jack product line.
Attributes
- Operation Type: Manual
- Capacity: 5000 Pound
- Maximum Lift: 15 Inch
- Mounting Type: Weld-On
- Type: Square Topwind
- Number Of Wheels: Without Wheel
- Color/ Finish: Gray Painted
- Swivel: No
- Retracted Height: 22.6 Inch
- Extended Height: 51.41 Inch
- Clearance: Adjustable
- Material: Steel
- Estimated Install Time (Hours): 0.5
Features & Benefits
- Zinc-Plated Inner Tube And Drop Leg
- 4.7 Inch Outer/Inner Tube Overlap Results In Optimal Side Load Performance
- 5/8 Inch Screw Stem Provides Insurance Against Screw Stem Twisting Off
- Patented Screw Nut Stop Prevents Screw And/Or Nut Damage When Jack Is Fully Extended
- Topwind Models – Bushing In Top Cap, Eagle Claw Grip
- 1/4 Inch Cross Pin Connects Gear Train To Screw Stem – Guards Against Shearing Jack Pin
- Limited 5 Year Warranty
