Multi Function Display Controller Switch – Furuno PSD003
The FURUNO PSD003 is a switch box and cable assembly designed for the Furuno NavNet TZtouch2 TZT2BB Black Box multifunction display system. It provides convenient system power control and also incorporates SD card access for compatible chart and navigation data. It is intended for marine electronics installations where the TZT2BB processor is used as the primary navigation and multifunction display system.
Specifications
- Compatible System: Furuno NavNet TZtouch2 TZT2BB
- Application: Marine navigation electronics
- Function: System switch box and SD card reader
- Width: 97 mm (3.8 in)
- Height: 97 mm (3.8 in)
- Depth: 106 mm (4.2 in)
- Weight: 0.75 kg (1.7 lb)
- SD Card Compatibility: SD card/chart data support
- Waterproof Rating: IP56 front panel
- Chassis Waterproof Rating: IPX2
- Operating Temperature Range: -15°C to +55°C
- Mounting Style: Flush Mount
- Cable: Attached connection cable
- Compatible Processor: TZT2BB
- Intended Environment: Marine use
Features
- Provides convenient power control for the TZT2BB system
- Integrated SD card reader provides access to compatible chart and navigation data
- Compact design is suitable for helm and marine electronics installations
- Flush-mount configuration provides a clean installation
- Water-resistant front panel is designed for marine environments
- Connects directly to the TZT2BB Black Box system
- Can be installed in an out-of-the-way location when a separate momentary power switch is used
- Designed as a dedicated component of the Furuno NavNet TZtouch2 system
