Bilstein 60mm Front Left Corner Module 41-284544 – BIL41-284544

60MM FRONT LEFT CORNER MODULE – BILSTEIN 41-284544

Bilstein B8 8112 (ZoneControl) CR suspension kits are a direct fit, position sensitive coilover designed for light trucks and SUV?s. ZoneControl CR is a revolutionary technology delivering position sensitive damping. The system incorporates a triple piston design, offering 3 stages of compression valving and 2 stages of rebound valving. The coilover module utilizes a threaded spring seat for ride height adjustability ranging from 0-3.8? (depending on application). The coilover is supplied with a remote reservoir for increased cooling and an accompanied, bolt-on anodized reservoir chassis mount. BILSTEIN B8 8112 (ZoneControl) CR position sensitive coilovers will offer unparalleled ride comfort during every day driving combined with maximum control over large suspension inputs.

• Adjustable Damping:Non-Adjustable
• Aftermarket Upper Arms Required:Yes
• Body Design:Smooth Body (Coilover)
• Body Diameter (ID):60mm
• Body Material:Steel
• Boot Included:No
• California Proposition 65:WARNING: Cancer &
• Reproductive Harm – www.P65Warnings.ca.gov
• Collapsed Length (IN):19.43
• Collapsed Length (MM):493.6
• Extended Length (IN):25.79
• Extended Length (MM):655.1
• Finish:Dampers: Zinc Plated/Springs: Black
• Internal Design:Monotube
• Lower Mount Type:Eye 16.1mm
• Optional Heavy Load Springs:N/A
• Reservoir:Yes
• Series:B8 8112 (ZoneControl CR)
• Spring Seat Included:Yes
• Title:Bilstein Shock Absorbers
• Upper Mount Type:Special
